Metallurgical Supplies - Polishing Cloths from OnPoint Abrasives

Metallographic Polishing Cloths

Cloth Abrasive (µm) Description Application
PlanarMesh 30 - 9 Aggressive, Metal Mesh Coarse/Intermediate
MasterPlan 30 - 3 Hard, Woven No Nap Coarse/Intermediate
GoldStandard 15 - 1 Hard, Woven, Dense Coarse/Intermediate
SimpleNylon 15 - 1 Medium Hardness, Woven, No Nap Coarse/Intermediate
ProDac 9 - 1 Soft, Woven, Synthetic Satin Intermediate/Final
MintPlus 3 - 0.02 Napped Synthetic Fibers, Durable Intermediate/Final
RedFelt 9 - 0.02 Soft, Durable, Wool Fiber Intermediate/Final
NoWeave 6 - 0.02 Flat, Non-Woven, Pressed Polyurethane Intermediate/Final
ChemPro 3 - 0.02 Dense, Non-Woven, Porous Final
FinalFloc 3 - 0.02 Soft, High-Nap Rayon Final
UltraViolet 3 - 0.02 Soft, High-Nap Final
ShortFinal 3 - 0.02 Soft, Low-Nap Final
SpecCloth 1 - 0.02 Firm, Medium-Nap Rayon Final

Metallographic polishing cloths

To prepare metallographic samples for analysis, an abrasive is used in combination with polishing cloths to remove surface deformations and reveal the material's structure.

It is essential to select high-quality polishing cloths since polishing is a crucial step in the preparation process. OnPoint offers metallographic polishing cloths that have undergone rigorous testing and are designed with Diabrasive Diamond and Alumabrasive Alumina to provide dependable results for each processed sample.

The choice of polishing cloth depends on the material being processed and the analysis requirements. OnPoint offers a range of fabrics, weaves, and naps to suit every application.

Polishing cloths are available with either PSA (adhesive) or Magnetic backings. The magnetic backing is a practical and efficient solution that produces consistent polishing results while minimizing cloth changeover time.



Filters

  • PlanarMesh Cloth - OnPoint Abrasives
    PlanarMesh Cloth - OnPoint Abrasives
    $60.00 - $240.00
    $60.00 - $240.00
    $60.00 - $240.00
    $60.00

    PlanarMesh Polishing Cloth for Metallographic Sample Preparation

    PlanarMesh is a unique metal mesh pad that provides excellent flatness on hard materials while preserving the specimen's edge. Specifically designe...

    View full details
    $60.00 - $240.00
    $60.00 - $240.00
    $60.00 - $240.00
    $60.00
  • MasterPlan Polishing Cloth zoom
    MasterPlan Metallographic Polishing Cloth
    $50.00 - $200.00
    $50.00 - $200.00
    $50.00 - $200.00
    $50.00

    MasterPlan Polishing Cloth for Metallographic Sample Preparation

    MasterPlan is a hard, woven cloth with no nap and good durability. This versatile cloth produces excellent flatness and high removal rates on a wid...

    View full details
    $50.00 - $200.00
    $50.00 - $200.00
    $50.00 - $200.00
    $50.00
  • GoldStandard Polishing Cloth
    $50.00 - $200.00
    $50.00 - $200.00
    $50.00 - $200.00
    $50.00

    GoldStandard Polishing Cloth for Metallographic Sample Preparation

    GoldStandard is a specially woven, nylon polishing pad for intermediate to fine polishing of harder materials. This cloth has no nap and is extreme...

    View full details
    $50.00 - $200.00
    $50.00 - $200.00
    $50.00 - $200.00
    $50.00
  • SimpleNylon Polishing Cloth
    $50.00 - $200.00
    $50.00 - $200.00
    $50.00 - $200.00
    $50.00

    SimpleNylon Polishing Cloth for Metallographic Sample Preparation

    SimpleNylon is a medium hard, woven, no nap polishing cloth. This pad produces fast removal rates with excellent flatness during coarse polishing s...

    View full details
    $50.00 - $200.00
    $50.00 - $200.00
    $50.00 - $200.00
    $50.00
  • ProDac Polishing Cloth
    ProDac Polishing Cloth
    $50.00 - $200.00
    $50.00 - $200.00
    $50.00 - $200.00
    $50.00

    ProDac Polishing Cloth for Metallographic Sample Preparation

    ProDac is a soft, woven cloth made of synthetic satin. This is an exceptional pad for intermediate to fine polishing of most materials. Use with di...

    View full details
    $50.00 - $200.00
    $50.00 - $200.00
    $50.00 - $200.00
    $50.00
  • RedFelt Polishing Cloth
    RedFelt Polishing Cloth
    $55.00 - $220.00
    $55.00 - $220.00
    $55.00 - $220.00
    $55.00

    RedFelt Polishing Cloth for Metallographic Sample Preparation

    RedFelt is a soft, napped, durable cloth made of wool fiber. Common choice for both intermediate and final polishing steps on a wide range of mater...

    View full details
    $55.00 - $220.00
    $55.00 - $220.00
    $55.00 - $220.00
    $55.00
  • NoWeave Polishing Cloth
    NoWeave Polishing Cloth
    $60.00 - $200.00
    $60.00 - $200.00
    $60.00 - $200.00
    $60.00

    NoWeave Polishing Cloth for Metallographic Sample Preparation

    NoWeave is an ultra-flat, non-woven cloth made of polyurethane fibers. Highly versatile pad for intermediate to final stages of polishing, Use with...

    View full details
    $60.00 - $200.00
    $60.00 - $200.00
    $60.00 - $200.00
    $60.00
  • MintPlus Polishing Cloth
    MintPlus Polishing Cloth
    $50.00 - $200.00
    $50.00 - $200.00
    $50.00 - $200.00
    $50.00

    MintPlus Polishing Cloth for Metallographic Sample Preparation

    MintPlus is a napped cloth made of synthetic fibers. This durable cloth can be used for one step polishing of steels and sintered carbides. Use wit...

    View full details
    $50.00 - $200.00
    $50.00 - $200.00
    $50.00 - $200.00
    $50.00
  • ChemPro Polishing Cloth
    ChemPro Polishing Cloth
    $140.00 - $250.00
    $140.00 - $250.00
    $140.00 - $250.00
    $140.00

    ChemPro Polishing Cloth for Metallographic Sample Preparation

    ChemPro is a dense, porous, non-woven cloth for materials preparation. Excellent final polishing cloth when combined with either ProPrep 2 Colloida...

    View full details
    $140.00 - $250.00
    $140.00 - $250.00
    $140.00 - $250.00
    $140.00
  • FinalFloc Polishing Cloth
    FinalFloc Polishing Cloth
    $50.00 - $170.00
    $50.00 - $170.00
    $50.00 - $170.00
    $50.00

    FinalFloc Polishing Cloth for Metallographic Sample Preparation

    FinalFloc is a soft, long nap, synthetic fiber polishing cloth. Exceptional final polishing pad on a wide range of materials. Use with diamond, alu...

    View full details
    $50.00 - $170.00
    $50.00 - $170.00
    $50.00 - $170.00
    $50.00
  • UltraViolet Polishing Cloth
    UltraViolet Polishing Cloth
    $50.00 - $200.00
    $50.00 - $200.00
    $50.00 - $200.00
    $50.00

    UltraViolet Polishing Cloth for Metallographic Sample Preparation

    UltraViolet is a soft, long nap cloth. Excellent for final polishing of most materials. Use with diamond, alumina, or colloidal silica 3 to 0.02 mi...

    View full details
    $50.00 - $200.00
    $50.00 - $200.00
    $50.00 - $200.00
    $50.00
  • ShortFinal Cloth
    $50.00 - $200.00
    $50.00 - $200.00
    $50.00 - $200.00
    $50.00

    ShortFinal Polishing Cloth for Metallographic Sample Preparation

    ShortFinal is a very soft, low nap final polishing cloth. The low profile of the Rayon fibers minimizes relief or edge rounding. Use with diamond o...

    View full details
    $50.00 - $200.00
    $50.00 - $200.00
    $50.00 - $200.00
    $50.00
  • SpecCloth Polishing Cloth zoom
    SpecCloth Polishing Cloth
    $50.00 - $200.00
    $50.00 - $200.00
    $50.00 - $200.00
    $50.00

    SpecCloth Polishing Cloth for Metallographic Sample Preparation

    SpecCloth is a firm, medium nap, Rayon cloth. Provides good edge retention during longer polishing steps. Use with diamond, alumina, or colloidal s...

    View full details
    $50.00 - $200.00
    $50.00 - $200.00
    $50.00 - $200.00
    $50.00
  • $36.00 - $36.00
    $36.00
    $36.00 - $36.00
    $36.00

    MagLink Plate 8-inch (each)

    MagLink Plate is part of the MagLink System used to fix consumables to your working wheel.  Simply adhere your desired polishing cloth or abrasive ...

    View full details
    $36.00 - $36.00
    $36.00
    $36.00 - $36.00
    $36.00
  • $47.00 - $47.00
    $47.00
    $47.00 - $47.00
    $47.00

    MagLink Plate 10-inch (each)

    MagLink Plate is part of the MagLink System used to fix consumables to your working wheel.  Simply adhere your desired polishing cloth or abrasive ...

    View full details
    $47.00 - $47.00
    $47.00
    $47.00 - $47.00
    $47.00
  • $53.00 - $53.00
    $53.00
    $53.00 - $53.00
    $53.00

    MagLink Plate 12-inch (each)

    MagLink Plate is part of the MagLink System used to fix consumables to your working wheel.  Simply adhere your desired polishing cloth or abrasive ...

    View full details
    $53.00 - $53.00
    $53.00
    $53.00 - $53.00
    $53.00
  • $34.00 - $34.00
    $34.00
    $34.00 - $34.00
    $34.00

    MagLink Base 8-inch (each)

    MagLink Base is part of the MagLink System used to fix consumables to your working wheel.  The MagLink base has a strong adhesive that will provide...

    View full details
    $34.00 - $34.00
    $34.00
    $34.00 - $34.00
    $34.00
  • $36.00 - $36.00
    $36.00
    $36.00 - $36.00
    $36.00

    MagLink Base 10-inch (each)

    MagLink Base is part of the MagLink System used to fix consumables to your working wheel.  The MagLink base has a strong adhesive that will provide...

    View full details
    $36.00 - $36.00
    $36.00
    $36.00 - $36.00
    $36.00
  • $40.00 - $40.00
    $40.00
    $40.00 - $40.00
    $40.00

    MagLink Base 12-inch (each)

    MagLink Base is part of the MagLink System used to fix consumables to your working wheel.  The MagLink base has a strong adhesive that will provide...

    View full details
    $40.00 - $40.00
    $40.00
    $40.00 - $40.00
    $40.00
